Magnavox/Emerson UPB0000SM001 T-Con Board

SKU:
sj-UPB0000SM001
$19.44
(You save $13.68)
$5.76
$19.44
(You save $13.68)
$5.76
180-Day Warranty
Ships same business day if ordered before 4pm CT!
We highly recommend matching your part number. Learn more

❄ HOLIDAY SALE! SAVE 10% WITH THE CODE SJHOLIDAY24 ❄

Partial part number (27754E) can be found on a sticker.

IMPORTANT: Horizontal lines on the screen are virtually NEVER caused by a bad T-con board. Horizontal lines indicate a defective LCD panel (screen).



Known Models

BrandModelsVersions
EMERSONLF461EM4DS2
LF461EM4 ADS3
MAGNAVOX46ME313V/F7DS3
46ME313V/F7ADS1,DS4
PHILIPS46PFL3908/F7DS2
46PFL3608/F7
RCALED46C45RQ
TCLLE46FHDE5510TATBAA
Notes:
ShopJimmy recommends ordering by part number whenever possible. Often times there are TV models that use more than one set of parts and/or panels.
Harmonized Code:
8529.90.06.00
Part Number:
UPB0000SM001
Manufacturer Part Number 1:
P&F UPB0000SM001
Part Type:
T-Con
Warranty:
180-Day Warranty
Board Number:
13YR_S60TMB3C2LV0.1|27754E
Part Usage:
LED/LCD
TV Panel Manufacturer:
Funai
TV Sizes:
46
Models:
LF461EM4 A
Models:
LF461EM4
Models:
46ME313V/F7
Models:
46ME313V/F7A
Models:
46PFL3908/F7
Models:
LED46C45RQ
Models:
LE46FHDE5510TATBAA
Brands:
tcl
Brands:
rca
Brands:
philips
Brands:
magnavox
Brands:
emerson
Panel Number:
U3GQ0XH|LVF460NE3L
Models:
46PFL3608/F7

Videos

What is a T-con board?

A T-con board — short for “timing control board” or “timing controller” — is found in LED and LCD TVs. This board converts the video signal from the main board and sends it directly to the screen to display the signal in the correct order and at the correct spot on the screen.

Which symptoms does a T-con board fix in a TV?

•  If your TV has no video, then the T-con board could be bad.

•  If your TV only has video on a fourth or half of the screen, then the T-con board could be bad.

*These are helpful tips to get you started and don’t represent accurate diagnoses for every TV model and failure. If you’re unsure of your diagnosis, we recommend checking out our YouTube channel or reaching out to a local TV technician for assistance.

How easy is it to replace a T-con board?

It's easy! Once you match the part number on your T-con board with the part number listed on this page to confirm compatibility, you’ll just need a screwdriver and the ability to remove the back of your TV and replace the board.
